| Welder Mode | MMA/TIG |
|---|---|
| Non-loading Voltage (V) | 70-75 |
| Load Voltage (V) | 22-30 |
| Max Welding Current (A) | 210 |
| Welding Current Range(A) | 50-210 |
| Load Duration Factor | 60% |
| Welding Rod Diameter | 1.5-4.0mm |
| Output Voltage (V) | 120V/220V/240V |
| Output Current (A) | 16A/9A/8A |
| Axillary Output (Optional) | DC 2kw |
| Axillary Output (Optional) | AC 3kw |
| Work Condition | Continuous |
| Engine Model | 192FE |
| Borex Stroke (mm) | 92 x 75 |
| Horse Power/Displacement | 199cc |
| Ignition System | Compression Ignition |
| Fuel Tank Capacity (L) | 12.5 |
| Starting System | Electric Start |
| Net/Gross Weight (Kg) | 108/112 |
| Carton Size (mm) | 730x530x640 |
| Q’ty 20’/40’/40”H | 93/198/264 |
