| Rated Input Voltage | 1 Phase 380V±10%, 50HZ/60/HZ |
|---|---|
| Rated Input Capacity | 15KVA |
| Welding Current | 40-350A |
| Welding Voltage | 14-35V |
| Rated Duty Cycle | 60% |
| Dimension (mm) | 640 x 335 x 640 |
| Weight | 31Kg |
| Suitable Thickness of Steel Plate (mm) | 2-20 |
| Suitable Welding Wire (mm) | 0.8/1.0/1.2 |
| Cooling Method | Force Fan-Cooling |
| Case Protection Class | IP21 |
| Executive Standard | GB15579.1-2004 |
Product Description
